Renault UKR CLIO R5 Megan connecting rods conrods
- Materials is high tensile 4340 forged steel
- Each rod is multi-stage heat-treated
- 100 percent machined,
- Is customized
- Product description: Renault UKR CLIO R5 Megan connecting rods conrods
Product introduction
Key Products Features
1.Materials is high tensile 4340 forged steel.
2.Each rod is multi-stage heat-treated,
3.X-rayed,
4.Sonic-tested,
5.Magnafluxed,
6.100 percent machined,
7.Shot-peened to stress-relieve the metal.
8.Precision cap alignment sleeves to positively locate each rod cap,
9.Aluminium bronze bushings for floating pin models,
10. Hardness is HRC33-38.
11.Bolts tesile strength
Style no | Engine model | pcs/set | (mm)c-c | B/E bore | S/E bore | B/E W | S/E W | bolt |
RENAULT-001 | UKR-BB | 4 | 144 | 51.6 | 21.005 | 25 | 25 | 3/8" |
RENAULT-002 | 136.5 | 4 | 136.5 | 51.59 | 21.005 | 25 | 25 | 3/8" |
RENAULT-003 | CLIO 144 | 4 | 144 | 51.6 | 21.005 | 25 | 22 | 3/8" |
RENAULT-004 | CLIO 150 | 4 | 150 | 51.6 | 21.005 | 25 | 22 | 3/8" |
RENAULT-005 | clio 142.5 | 4 | 142.5 | 51.6 | 21 | 24.8 | 18.2 | 3/8" |
RENAULT-006 | clio 152 | 5 | 152 | 51.59 | 21.005 | 25 | 22 | 3/8" |
RENAULT-007 | JF144-21 | 4 | 144 | 51.6 | 21.015 | 25 | 22 | 3/8" |
RENAULT-008 | 144(X) | 4 | 144 | 51.6 | 21.005 | 25 | 25 | 3/8" |
RENAULT-009 | R5 TURBO ll | 4 | 128 | 47.614 | 20.02 | 21.8 | 21.8 | 5/16" |
RENAULT-010 | Renault | 4 | 128 | 47.614 | 20.002 | 21.8 | 21.8 | 3/8" |
RENAULT-011 | R5 TURBO ll | 4 | 131 | 47.614 | 20.02 | 21.8 | 21.8 | 3/8" |
RENAULT-012 | 5 turbo | 4 | 128 | 47.62 | 20 | 21.8 | 21.8 | 5/16" |
RENAULT-013 | R5 TURBO ll | 4 | 133 | 47.614 | 20.02 | 21.8 | 21.8 | 3/8" |
RENAULT-014 | 128 | 4 | 128 | 47.614 | 20 | 21.8 | 21.8 | 3/8" |
RENAULT-015 | R5 | 4 | 128 | 47.615 | 20.01 | 21.8 | 21.8 | 3/8" |
RENAULT-016 | R5 | 4 | 128 | 47.625 | 20 | 21.7 | 21.7 | 5/16" |
RENAULT-017 | 150 | 4 | 150 | 47.625 | 20 | 21.8 | 21.8 | 3/8" |
RENAULT-018 | R5 | 4 | 131 | 47.625 | 20 | 21.7 | 21.7 | 5/16" |
RENAULT-019 | JK128 | 4 | 128 | 47.615 | 18.015 | 21.8 | 18 | 3/8" |
RENAULT-020 | Clio 1600CC | 4 | 150 | 51.6 | 21 | 24.8 | 18 | 3/8" |
RENAULT-021 | Clio L-144 | 4 | 144 | 51.6 | 20 | 26.95 | 20 | 3/8" |
RENAULT-022 | Clio Maxi | 4 | 150 | 48.655 | 18 | 24.9 | 19 | 3/8" |
RENAULT-023 | Clio MAXI L-150 | 4 | 150 | 48.655 | 18 | 24.9 | 16 | 3/8" |
RENAULT-024 | clio V6 | 4 | 154 | 54.9 | 22 | 21.4 | 20 | 5/16" |
RENAULT-025 | Alpine L-138.5 | 4 | 138.5 | 51.6 | 21 | 26.85 | 26.85 | 3/8" |
RENAULT-026 | Renault | 4 | 136.5 | 51.6 | 20 | 26.85 | 26.85 | 3/8" |
RENAULT-027 | CLIO L-144 | 4 | 144 | 51.6 | 21 | 24.8 | 18 | 3/8" |
RENAULT-028 | Megan | 4 | 128 | 47.55 | 19 | 21.8 | 21.8 | 3/8" |
Payment:T/T ,Paypal.
Quality: Stable and reliable
Strict QC management
Certification: ISO/TS16949 and ISO14001
Beam Style:H-beam/I-beam
Bushing:Bronze bushing
Rod Wrist Pin Style:Floating/ Press Fit
Packaging Details:Rust preventing oil packing,Plastic, Cardboard,Carton,Iron case,Wooden case
Delivery Detail:30days
If you can’t find the correct one, please contact us email: manager@victorengineparts.com, we will help find it for you or develop it for you.
